Quantity:

(See important SIM card info at bottom of page)

NOTE: Programming Cable and Voice Module sold separately.

(More antenna, autodialer, cellular, and enclosure options are available. Contact us for a quote on a custom-built kit to suit your needs.)

---

Risco Group's Advanced GSM/GPRS Module is a revolutionary stand-alone cellular alarm system!
No need for a landline!

This device is truly revolutionary. The AGM has four dry contact inputs and four outputs. It utilizes SIM cards from GSM providers, so you do not need a land line! The free programming software even lets you configure text messages for alarm notification as well as voice calls (with optional voice module). Requires XP, Vista, and Windows 7 - Professional Version or Greater - NOT Home Versions.

The AGM can be used simply to generate a dial tone via cellular. Just remove the SIM card from a GSM cell phone and put it in the AGM. Then just attach your house phones, autodialer, or other equipment* that needs a dial tone!
(*"Modem speak" cannot be emulated over cellular.)

The AGM can also be used as a stand-alone GSM cellular alarm system. Hook security or environmental sensors (any dry contact sensor) right to it, and it will text you when they are tripped. Add the voice module, and it will call you with a custom-recorded voice message! The AGM is the PERFECT solution for monitoring remote sites.

The AGM is also a great replacement for sunsetted analog units such as the Motorola bag phone.

Features & Options

• Includes SIM card**
  (See important SIM card info at bottom of page)

• Four dry contact (NO/NC) inputs
• Four outputs (1 dry contact, 3 powered @ 14.4VDC, 100mA)
• Built-in power failure monitoring with adjustable delay
• Free programming software (see below)
• Provides dial tone to other devices, either primary or as backup to PSTN
• Auxiliary power terminals can power other devices (14.4DC, 1.5A)
• Event driven SMS (text) messages
• Event driven voice messages (with optional voice module)
• Event driven GPRS email messages
• SMS (text msg) remote control with acknowledgment of command execution
• DTMF remote control support
• GMS Signal supervision and level measurement
• Remote Upload/Download configuration via GSM Data channel (for communication with central monitoring station or AGM software)
• Phone calls can be made using an attached telephone (simulated telephone live via GSM)
• Battery backup included in this kit
• Optional voice module (p/n RP200GSV000A, see below)
• Optional computer cable (p/n RP128EUSB00A, see below)

The AGM can be programmed in two ways:

Via any GSM cellular phone (using SMS commands, aka text messages).

Via the free AGM Configuration Software - Requires XP, Vista, and Windows 7 - Professional Version or Greater - NOT Home Versions.

When using the free AGM Configuration Software, you can connect in three ways:

Locally via the RP128EUSB00A Computer Cable

Remotely via SMS* (send each parameter from a cell phone as an SMS command, aka text message)
*Remote Programming via the SMS method does not allow for changing input labels (default labels such as "Intruder Alarm" will be sent as alarm messages).

Applications

• Provide a dial tone to just about ANYTHING! (Standard phones, alarm panels*, etc.)
  *Cellular dial tones cannot emulate modem-speak, which may be required by a monitoring station.
• Use with an alarm system as primary communication or as a backup dial tone in the event that landline signal is lost. Can also generate an outgoing alarm message letting you know that the landline (PSTN) signal has been lost!
• Control devices remotely: Outputs can be activated by an alarm condition or via text message!
  The AGM can provide auxiliary power (14.4 VDC) to the outputs in order to power attached devices (sirens, strobes, etc).
• Add security or environmental sensors (anything NO or NC) to create a stand-alone, complete monitoring system with no need for a landline! (See "Wired Sensors & Accessories" category)

Downloads

Click here to download the Brochure for this product

Click here to download the User Manual for this product

Click here to download the Installation & Programming Manual for this product

Click here to download the Voice Module Instructions for this product

Click here to download the Free AGM Configuration Software

Click here to download the AGM Software Configuration Guide (~1MB)

---

This unit is for use with any type of alarm application. If you are interested in the WisDom-specific version of this product (RP128GSXMUSA), please go to the WisDom Accessories category.

---

Example screenshot from AGM computer software:

---

More Pictures:









**SIM Card Information:

• Includes SIM card. Click here for plan information: AGM GSM Cellular SIM Card Plans, and click here to check coverage for those plans.
• Also supports UNLOCKED* SIM cards from AT&T and T-Mobile work well with the AGM. SIM cards can usually be purchased independent of a phone (by calling the main 800 number of the cellular provider). *AT&T has started locking some of their GoPhone cards...make sure to obtain an UNLOCKED SIM card if you are using AT&T. Nextel, TracFone, and Boost Mobile SIM cardsWILL NOT work with the AGM. Other providers may or may not work, contact them directly to ask about compatibility.
